The Nanomodules Font is a 6HP 2-pole multimode filter that provides a huge, liquid sound perfect for basslines, percussion synthesis, and more. With simultaneously accessible lowpass and bandpass outputs, it is perfect for bringing thick, wet, filtering to any sound source.
It responds amazingly to sounds in any part of the frequency spectrum, and can even be pinged with low-frequency signals to create dampened percussion sounds. It offers CV control of cutoff and resonance, each with dedicated attenuverters—allowing a large variety of sonic animations from traditional sweeps to FM and more.
Font produces a clean sine wave at high resonance settings—use this in conjunction with the 1V/Oct control input for a clean sine oscillator, or apply a pitch envelope to create huge kick and tom sounds.
Features:
- 2-pole Low Pass and 2-pole Band Pass outputs available simultaneously
- Resonance extends into self-oscillation
- CV inputs for cutoff frequency and resonance, each with dedicated inverting attenuators
- 1V/Oct pitch input
Video:
Product Specs
- Item Number: 25636
- Make:
- Model:
- Condition:
- Finish: Black
- Categories: ⇒
- Function:
- Made In: Spain
- MPN: NAN-FON
- Modular Grid: Eurorack
- Dimensions: 6 HP 15 mm deep
- Power: 22 mA 12V 25 mA -12V 0 mA 5V
